PACVD (Plasma-Assisted Chemical Vapor Deposition)
PACVD (Plasma-Assisted Chemical Vapor Deposition) 1. The thickness of the coating can reach more than 3 μ m 2. The adhesion of the coating is l-grade 3. The hardness of coating 2200-2600HV 4. Dry friction coefficient (for steel) is 0.1-0.2
- Product Introduction
IKS PVD Technology (Shenyang) Co., Ltd. is one of the most reliable manufacturers and suppliers of pacvd (plasma-assisted chemical vapor deposition) in China, featured by quality products and low price. If you're going to wholesale cheap pacvd (plasma-assisted chemical vapor deposition) made in China, welcome to get quotation from our factory.
| PACVD (Plasma-Assisted Chemical Vapor Deposition) |
Diamond-Like(DLC) Coating machine
1. The thickness of the coating can reach more than 3 μ m
2. The adhesion of the coating is l-grade
3. The hardness of coating 2200-2600HV
4. Dry friction coefficient (for steel) is 0.1-0.2
| DLC coating | 800 | 801 | 802 |
| Effective Space | Φ1060×H750mm | Φ800×H800mm | Φ900×H1500mm |
| Applied Technical | Ion beam | PACVD | PVCVD |
| Magnetron cathod length | 850 | 1020 | 1680 |
| Cycle Time | 13--15h | 8h | 8-9h |
| Axis Qt | 12 | 16 | 12 |
| Standard turntable load | 500kg | 500kg | 500kg |
| Applied range | mold, mold accessories, textile industry, 3C products, parts with a coeficient of friction and other products. | ||
